Mejore su experiencia visual con PROLED, que ofrece una calidad de imagen excepcional diseñada para aplicaciones comerciales en interiores. Ofrece imágenes nítidas y vibrantes que cautivan y resuenan.

LEDs

• Pixel pitch: 2.604mm
• Pixel configuration: 1RGB
• LED type SMD
• Ics ICN1065S
• LED light encapsulation SMD1515

Module

• Pixel pitch 2.604mm
• Pixels per sqm. 147,456 pixels
• LEDs qty. per sqm. 147,456 pcs
• LED module resolution 96×96
• LED module size 250x250mm

Cabinet

• LED cabinet resolution 192(W) x 192(H) pixels
• LED cabinet dimension 500mm×500×80 mm
• LED cabinet weight About 6kg
• LED cabinet Area 0.25 sqm.
• Max Brightness 800 ~1000 mcd/sqm
• Viewing angle Horizontal: 140°±5°; Vertical: 140°±5°
• Grey grade 14 bits
• Frame frequency ≥60Hz/s
• Display refresh rate ≥7680Hz
• Scan mode 1/32 scan
• Fan no fans
• Cabinet color black

Power supply

• Power consumption (max.) <450 watts/sqm.
• Power consumption (average) <270 watts/sqm.

Mechanical design

• Material Die-casting Aluminium
• Ingress protection IP43
• Serviceability Rear service

Operation

• Storage environment Temperature: -40℃－60℃; Humidity: 10%－85%RH
• Operating environment Temperature: -20℃－65℃; Humidity: 10%－90%RH
• Lifespan (typical) ≥100,000 hours
• MTBF ≥10,000 hours
• Source compatibility CVBS,YC, YUV,RGB, DVI, SDI, HD-SDI, HDMI
