• 8 digital signal processing effects engines
• 17 MIDAS PRO motorised 100 mm faders
• Daylight viewable 5” full colour TFT display screen
• 32 x 32 channel USB 2.0 audio interface
• DAW remote control emulations of Mackie Control* and HUI* protocols
• Optional wireless remote control with MIDAS Apps for iPhone* and iPad*
• Auto-ranging universal switch-mode power supply
• 3-Year Warranty Program*
• Designed and engineered in the U.K.

ESPECIFICACIONES

• Type:Digital
• Channels:40
• Inputs – Mic Preamps:16 x XLR
• Phantom Power:16 x Channels
• Talkback:Yes
• Inputs – Other:6 x 1/4″ (Aux), 1 x Stereo (RCA), 1 x XLR (Talkback)
• Inputs – Digital:1 x MIDI
• Outputs – Main:8 x XLR, 2 x 1/4″
• Outputs – Digital:1 x MIDI
• Outputs – Other:6 x 1/4″ (Aux), 1 x Stereo (RCA)
• Data I/O:1 x Ultranet, 2 x AES50
• USB:1 x Type B, 1 x Type A
• Computer Connectivity:USB (32 x 32)
• Busses/Groups:25 x Bus
• Headphones:1 x 1/4″
• Faders:17 x 100mm (Motorized)
• EQ Bands:31-band Graphic
• Effects:Yes
• DAW Control:Yes
• Rackmountable:Yes

M32R

Digital Console for Live and Studio with 40 Input Channels, 16 MIDAS PRO Microphone Preamplifiers and 25 Mix Buses

• Live performance and studio recording digital console with up to 40 simultaneous input channels
• 16 award-winning MIDAS PRO microphone preamplifiers
• 25 time-aligned and phase-coherent mix buses
• AES50 networking allows up to 96 inputs and 96 outputs
• Open architecture allows for future 96 kHz operation
• 192 kHz ADC and DAC converters for outstanding audio performance
• Industry-leading design by Bentley* Motors Designer
• High-performance aluminium and high-impact steel structure
• Rack mount brackets included for ultimate flexibility
• 40 bit floating point digital signal processing

• 8 DCA and 6 mute groups
• 8 digital signal processing effects engines
• 17 MIDAS PRO motorised 100 mm faders
• Daylight viewable 5” full colour TFT display screen
• 32 x 32 channel USB 2.0 audio interface
• DAW remote control emulations of Mackie Control* and HUI* protocols
• Optional wireless remote control with MIDAS Apps for iPhone* and iPad*
• Auto-ranging universal switch-mode power supply
• 10-Year Warranty Program*
• Designed and engineered in the U.K.





Designing A Future Classic

Our goal for M32R was to combine the best of classic British console designs with advanced modern technology to completely redefine what a rack mountable digital desktop mixing console can offer.

We began the industrial design process by…

more >

---



Why High-Performance Cars?

Simply because the design teams at Aston Martin*, Bentley*, Rolls Royce*, and other leading manufacturers are skilled at introducing innovative technological advancements while simultaneously maintaining the feel, essence, and intangible qualities…

more >

---



The Landmark in Console History

A close look at M32R reveals that the styling is completely new in every sense of the word. Rajesh Kutty’s automotive-inspired design elements mesh perfectly with a recognisable MIDAS signature, setting the M32R apart from any other console. Its…

more >

---



MIDAS is the Epitome of Excellence

In 2013, MIDAS approached me to create a new design language for MIDAS and with it a new mixing console. Having designed for Bentley, I am intimately familiar with the challenge of transforming a brand while retaining the precious heritage –…

more >

---



Industry-Leading 192 kHz Precision

The ground-breaking M32R console combines legendary MIDAS sound quality with advanced digital technology, future-proof 96 kHz capable open architecture design and industry-leading 192 kHz ADC and DAC converters, creating a revolutionary…
